High Current / High Heat Radiation

PCB for High Current and High Heat Radiation

Metal Core / Metal Base PCB
By adopting a metal core and metal base, we provide PCB with high heat radiation.

•
  Metal base
•
  Metal core

Thick Copper PCB

We have superiority in thick copper etching technology and lamination technology.

Features

Compared to the maximum copper foil thickness of 70um for general products, our products have a copper thickness of 175-215um and have succeeded in improving heat radiation characteristics.

Characteristics

5-Layer interstitial via hole structure

Applications

• Compact power supply board
• High current board : 10A or more
